Haco HDE 6′ x 1/4″ Hydraulic Shear. Brand: Haco, Model: HDE, Serial #: 67092, Approx. Shipping Weight: 8,000 Lbs., Approx. Shipping Dimensions: 9′ L x 8′ W x 6′ H, Max Cutting Thickness: 1/4″ Mild Steel, Max Cutting Width: 80″, Strokes Per Minute: 10 – 25, Back Gauge Travel: 39″, Motor HP: 15, Electrical: 230V/3PH. Equipped with Front Operated Back Gauge Controller, Powered Angle Blade Adjustment, Squaring Arm, Inch/Single Stroke Operation.
Haco Atlantic Model HDE 6′ x 1/4″ Hydraulic Shear
Max Cutting Thickness..............................1/4″ Mild Steel
Max Cutting Width..................................80″
Strokes Per Minute.................................10 – 25
Back Gauge Depth Minimum...........................1"
Back Gauge Depth Maximum...........................40"
Back Gauge Travel..................................39″
Square Arm.........................................40"
Hydraulic Pressure At Hold Downs...................1,400 PSI
Hydraulic Pressure At Shear Cylinders..............3,400 PSI
Hydraulic Oil Capacity.............................70 Gallons
Motor HP...........................................15
Electrical.........................................230V/3PH.
Approx. Shipping Dimensions........................R-L 9' X F-B 8" X Height 6'
Approx. Shipping Weight............................8,000 Lbs.
Equipped with:
Front Operated Back Gauge Controller...............Yes
Powered Angle Blade Adjustment.....................Yes
Squaring Arm.......................................Yes
Inch/Single Stroke Operation.......................Yes
