9" X 49" Used Bridgeport Series l

9" X 42" Used Bridgeport Series l
Table Size..........................................9" X 49"
Table-W.............................................9"
Table-L.............................................42"
Travel-Long.........................................31"
Travel-Cross........................................12"
Table Load..........................................750 Lbs.
Table Height Above Floor............................47-1/4"
Spindle Taper.......................................R- 8
Spindle Speeds Variable.............................60 To 4,200 Rpm's
Spindle Feeds.......................................0.001 To .003 I.P.R.
T-Slot Centers......................................3 @ 2.5"
T-Slott Size........................................0.625"
Spindle Quill Travel................................5"
Spindle Tilt........................................+/- 45 Degrees
Spindle Swivel......................................+/- 45 Degrees
Spindle To Table Min / Max..........................6-3/4" / 18-3/4"
Spindle Diameter....................................1-7/8"
Quill Diameter......................................3-3/8"
Knee Travel.........................................16"
Milling Capacity (Mild Steel).......................3/4"
Boring Range (Mild Steel)...........................6"
Main Motor..........................................2 Hp.
Floor Space.........................................R To L 72" X F To B 72"
Machine Height......................................84"
Weight..............................................2,500 Lbs.
Newall 2 Axis D.R.O. System.........................Yes
Power Draw Bar......................................Yes
Vise 6".............................................Yes
Collets.............................................Yes
Hold Down Kit.......................................Yes

Note: Machine has been cleaned and cycled.

Prices Subject To Change
