3.9" Used Tos Manual Table Type Horizontal Boring Mill Completely Rebuilt By FERMAT In 2025

Spindle Size........................................3.93
Spindle Taper ISO...................................# 50
Spindle Speeds Main.................................7.1 To 1,120 Rpm's
Spindle Feeds (16)..................................0.0008 0 .025
Spindle & Head Stock Rapid Traverse.................1,600 IPM
Spindle Travel W Axis...............................35"
Spindle Head Travel Up & Down Y Axis................49"
Saddle Travel In & Out X Axis.......................48"
Rotary Table Size...................................44" X 49"
Table Travel Cross X Axis...........................63"
Saddle And Table Feeds .............................0.02 To .025
Facing Head Diameter ...............................23.6"
Facing Head Slide Travel............................8.276"
Max. Diameter Of Facing Head........................35.43
Facing Head Feeds...................................7.1 TO 224 IPM.
Rotary Table Feeds..................................0.056 To .025
Table Load..........................................6,000 Lbs.
Main Motor..........................................15 Hp.
Floor Space Width & Length..........................135" X 267"
Height..............................................120"
Weight..............................................30,860 Lbs.
D.R.O...............................................5 Axis Yes
Power Tool Lock.....................................Yes
Harden & Ground Bed & Cross Ways....................Yes
Built In Outriggers For Table Support...............Yes
Tail Stock..........................................Yes
Rapids..............................................Yes
Transformer.........................................Yes

Options:
Right angle head FP100/40 $15,470.00
Boring bar 80x2500 (Delivery 2 months)..............$11,200.00
Boring bar 100x250 (Delivery 2 months)..............$11,700.00
Short knife holder ND 100 (Delivery 2 months).......$2,100.00
Long. telescope knife holder TD 50/4
(Delivery 2 months).................................$3,100.00

FEATURES:
Machine with modern Motor and Electrics
5 Axis DRO Heidenhain POSITIP 880
Scales on X, Y, Z and W-Axis
B-Axis measurement with a built-in rotary encoder and 4x90° Optical Readout
Long life Spindle and Spindle Bearings
Central Lubrication System for All Axes
Telescopic Covers
24 Inch Facing Head With Maximum Face Milling Diameter 35.5”
Facing Head
Documentation
CE Electrical Specifications
