20"X60" New Masteel Engine Lathe Model Maxcut ML-2060
Heavy duty geared head; hardened and ground gears.
86mm. 3-3/8 inch hole through spindle.
3-point supported spindle using 2 precision taper roller bearings and 1 ball bearing.
12 steps spindle speeds 20 – 1800 rpm. shift in geometric progression.
Forced spray lubrication system used for headstock.
One piece casting base for maximum rigidity.
One shot lubrication pump supply oil cross slide and bed-ways.
Adjustable overload clutch in apron to ensure proper cutting load.
Cross slide screw permanently immersed in oil and supported by thrust bearing.
Quick-change universal gearbox for inch, metric, DP, MP, threading, and multiple thread.
NOMINAL SIZE Inch MM
Swing over Bed 20" 510 mm
Swing over Cross Slide 13.5" 342 mm
Swing over Gap 28.750" 730 mm
Length of Gap 11.750" 300 mm
Height of Center 10" 255 mm
Distance Between Centers 60" 1,500 mm
Bed
Width of Bedways 13" 330 mm
Total Length of Bed 98" 2,510 mm
Width in front of face plate 6.750" 175 mm
Spindle nose mounting D1-8 CAMLOCK
Spindle bore 3-3/8" 86 mm
Taper of spindle bore Morse Taper #5
Number of spindle speeds 12
Range of spindle speeds 20-1800 R.P.M.
CARRIAGE
Total travel of cross slide 10.250" 260 mm
Total travel of top slide 5.125" 130 mm
Max. size cutting tool 1" 25 mm
TAIL STOCK
Total travel of tailstock barrel 6" 150 mm
Taper in tailstock barrel Morse Taper #5
Diameter of barrel 2.562" 65 mm
THREADS
Lead screw diameter Dia.1-3/8 35 mm
Lead screw pitch 4 TPI 6 mm
Number of inch threads 48
Range of inch threads 2-72 TPI
Number of metric pitches 48
Range of metric pitches 0.2-14 mm
Number of Diametral pitches 4
Range of Diametral pitches 8-60 D.P.
Number of Module pitches 24
Range of Module pitches 0.2-3.5 M.P. FEEDS
Feed rod diameter 1" 25 mm
Number of feed change 36
Range of longitudinal feeds inch 0.0025-0.07in/rev.
Range of longitudinal feeds inch 0.06-2.00mm/rev.
Range of cross feeds 0.0010-0.03in/rev.
Range of cross feeds 0.03-0.80mm/rev.
MOTOR
Main spindle motor 10 Hp. 7 k
Coolant pump motor 1/8 Hp. 0.1 kw
Machine net weight 4,630 2,100 kgs
Included In Price
12 inch 3 jaw chuck top reversing jaws
16 inch 4 jaw chuck
Roller Steady Rest 1" To 7"
Follower Rest
Taper Turning Attachment
Optional
Newall D.R.O. 2 Axis Installed $5,800.00
Machine made in Tiawan.
**SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
