EUMACH HSM-550U-5X 5-AXIS MACHINING CENTER

Description

EUMACH – ALWAYS A STEP AHEAD
Outstanding precision, productivity and reliability make Eumach 5 axis machining centers the ideal solution for high speed 5 axis machining applications such as aluminum, titanium and special alloys. The HSM series has rapidly been increasing in demand in the aerospace, medical optical, automotive and other industries.
With 30-year experience Eumach offers high quality 3-5 axis machining technology. Eumach has been developing groundbreaking solutions to the challenges of this growing market - from the smallest 255mm diameter table up to 1650mm diameter - or by using 2 axis milling heads on large size double column machines.
The following benefits from these solutions are significant:
Fewer set-ups:
maximum number of tasks achieved in a single operation with less misalignment
Less handling:
minimal risk of collision damage
High flexibility:
machining centers with 24, 32 or 40 tool magazines with automatic tool changer
Reduced cycle time:
using high-speed cutting function from the latest advanced CNC controls
Reduced lead times:
less operations
Common platform:
suitable for different parts
Low cost of ownership:
maximum cost-benefit ratio through entire lifecycle
VALUE STANDARD EQUIPMENT

X/Y/Z travel: 800/610/510mm
Table: 550mm Dia.
Tilt range +120 to -42 degrees
Automatic tool changer: arm type, 32 tool position
CAT 40 taper
Spindle Speed:12000 RPM with 2 step for heavy duty cut on low speed
20Hp /25Hp (30 min) 2 speed spindle motor
Through spindle Coolant
Chip conveyor
