21" X 120" New Webb Engine Lathe Model MA-21120-3

21" X 120" New Webb Engine Lathe With Gap
Swing Over Bed Ways..........................................21.2"
Swing Over Cross Slide.......................................14.1"
Swing In Gap.................................................28.3"
Center Height................................................10.6"
Center Distance..............................................120"
Spindle Hole.................................................3"
Cross Slide Travel...........................................12.9
Compound Rest Travel.........................................5.9"
Spindle Speeds (18)..........................................25 To 1,545 Rpm's
Spindle Nose.................................................D-1-8
Feeds Cross..................................................0.003 To 0.44 I.P.R.
Feeds Long...................................................0.06 To 0.88 I.P.R.
Threads Inch.................................................4 To 56 T.P.I.
Threads Metric...............................................0.05 To 7 MM
Lead Screw...................................................4 TPI
D.P..........................................................8 To 112 T.P.I.
Module.......................................................0.05 To 3.5 T.P.I.
Tail Stock Quill Diameter....................................2.9"
Tail Stock Quill Travel......................................6.7"
Tail Stock Taper.............................................# 5 Morse
Main Motor...................................................10 Hp. 220 / 440/
Machine Dimension............................................R-L 169"X F-B 4'
Height.......................................................67"
Weight.......................................................4,500 Lbs.
Square Tool Post.............................................Yes
Foot Brake...................................................Yes
Coolant Pan..................................................Yes
Thread Dial..................................................Yes
Hardened And Ground Ways.....................................Yes

Machine Options:
All prices and specifications are subject to change without notice:
MA 21” Series Upgrade to 15 HP...............................$1,790.00
MA 21” Inverter Head with CSS and PLC for 10 HP..............$6,390.00
MA 21” Upgrade to 15HP from 10HP with Inverter Head..........$2,580.00
MA 21” Series 4“ Spindle Bore A2-11 Mount....................$4,990.00
MA 21” Series 6” Spindle Bore A2-11 Mount....................$8,600.00
MA 21” SeriesDouble Chuck System Rear Adaptor Plate..........$1,790.00
MA 21” Series Roller Steady Rest.............................$790.00
MA 18/21” Rapid Traverse Motor on Apron......................$1,890.00
Follow Rest..................................................$575.00
Micrometer Carriage Stop.....................................$390.00
5 Position Micrometer Carriage Stop..........................$490.00
Taper Attachment.............................................$1,990.00
Installation Of Taper Attachment.............................$450.00
Quick Change Tool Post and 4 Tool Blocks.....................$1,125.00
Full Length Splash Guard 40” and 60” Centers Machine.........$595.00
Full Length Splash Guard 80” and 120” Centers Machine........$795.00
Digital Read Outs – Acu-Rite and Newall
Newall 2 Axis Digital readout System ........................$5,350.00
Optional Chucks Number of Jaws / Description Retail Price
3-JAW 10” D-1-8 CAM LOCK MOUNT...............................$1,090.00
3-JAW 12” D-1-8 CAM LOCK MOUNT...............................$1,590.00
4-JAW 16” D-1-8 CAM LOCK MOUNT...............................$2,490.00
Gator Chucks
Chuck Size 12" 3-Jaw D-1-8 Cam Lock Mount....................$1,990.00
Chuck Size 16" 4-Jaw D-1-8 Cam Lock Mount....................$2,490.0
Gator Chuck Size 12" 3-Jaw with 2 piece jaws D-1-8 Cam Lock
Mount Steel Body.............................................$2,950.00
Gator Chuck Size 12" 4-Jaw with 2 piece jaws D-1-8 Cam Lock
Mount Semi-Steel Body........................................$2,336.00
20” Face Plate D-1-8.........................................$860.00
Voltage:
Rewire to 440V...............................................$450.00
All prices and specifications are subject to change without notice:
