49"VT 1250 RM New Ameri-Seiki CNC Vertical Boring Mill

Control Fanuc Control OiT
Control Fanuc OiT
Table Diameter..................................49.2"
Max. Swing Diameter.............................62.9"
Max. Turning Diameter...........................53.1"
Max. Turning Height.............................49.2"
Max Spindle Load................................5,000 Kg
Spindle Speed...................................2 To 3,000 Rpm's
Spindle Max. Output Torque......................12,500 NM
X -Axis Travel..................................58"
Z-Axis Travel...................................35.4"
Rail Travel.....................................31.5"
X-Axis Rapid Feed Rate..........................12,000 MM/MIN
Z-Axis Rapid Feed Rate..........................10,000 MM/Min
Cutting Feed Rate...............................0.01 To 50 MM/REV
Manual Feed Rate................................0 To 1,260 MM/MIN
Tool Storage Capacity...........................16 Tools
Tool Taper......................................BT 50
Max Tool Weight.................................110 Lbs.
ATC Max Load....................................450 Kg.
ATC Tool Change Time............................30 Sec.
#1 Spindle Motor (Cont./30min.).................37/45 Hp.
#2 Spindle Motor................................7.5/11kw
#1 Spindle Speed................................2 To 300 Rpm's
#1 Spindle Max. Output Torque...................12,500 Nm
#2 Spindle Speed................................2,400 Rpm's
#2 Spindle Max. Output Torque...................550 NM
Spindle Main Motor..............................60/75 Hp.
X- Axis Servo Motor.............................7.0 KW
Z-Axis Servo Motor..............................7.0 KW
Rail Lifting Motor..............................2.25 KW
Hydraulic Motor.................................3.75 KW
Chip Conveyor Motor.............................0.375 KW
Coolant Pump Motor..............................1.5 Hp.
Machine Size....................................185" X 229"
Machine Height..................................216"
Machine Weight..................................72,753 Lbs.
Machine Power...................................90 KVA
Manual 4 Jaw Chuck..............................Yes
Two Speed ZF Gearbox............................Yes
Automatic Tool Changer (16 Tools)...............Yes
Live Tooling....................................Yes
Foot Switch.....................................Yes
Nitrogen Automatic Balancing....................Yes
Chip Conveyor...................................Yes
High Pressure Coolant...........................Yes
Half Machine Cover..............................Yes
Electrical Cabinet Heat Exchanger...............Yes
Oil & Water Separator...........................Yes
Auto Lube System................................Yes
A/C For Spindle Gear Box........................Yes
Tool Kit........................................Yes
