Swing Over Bed Ways 18-1/2"
Swing Over Cross Slide 10"
Center Distance 78"
Spindle Hole 1-1/2"
Spindle Speeds 13 To 1,000 Rpm's
Spindle Nose D1-6
Chuck Size 16" 4 Jaw
Feeds .0075 To 240
Threads Inch 1-1/2 To 90 TPI
Tail Stock Quill Diameter 4-1/2"
Tail Stock Quill Travel 10"
Tail Stock Taper #4 Morse
Main Motor 10 Hp. 220 / 440
Floor Space Length & Width 134" X 84"
Height 84"
Weight 7,500 Lbs.
Steady Rest 6" Brass Pad Type Yes
Coolant Pans Yes
Taper Attachment Yes
Thread Dial Yes

Note: Machine has been cleaned, painted and cycled.
