22" X 60" Whacheon Engine Lathe Model HL 580

Swing Over Bed Ways...................................22"
Swing Over Cross Slide................................14-11/64"
Swing In Gap..........................................31"
Gap Length............................................10-5/8"
Bed Width.............................................16-1/2"
Center Distance.......................................60"
Spindle Hole..........................................3-1/32"
Spindle Speeds........................................28 To 1,350 Rpm's
Spindle Nose..........................................D-1-8
Feeds Cross...........................................0.00015 To 0212 I.P.R.
Feeds Long............................................0.0014 To .0196 I.P.R.
Threads Inch..........................................2 To 80 T.P.I.
Threads Metric........................................0.25 To 14 MM
D.P...................................................8 To 112 T.P.I.
Module................................................0.05 To 3.5 T.P.I.
Tail Stock Quill Diameter.............................3"
Tail Stock Quill Travel...............................6"
Tail Stock Taper......................................# 5 Morse
Main Motor............................................10 Hp.
Machine Dimension.....................................146.2 R-L X 48" F-B
Machine Height........................................65
Weight................................................7,256 Lbs.
Driving Plate.........................................11-3/4"
Change Gear...........................................60 T
Face Plate Gap Bed Only...............................17-3/4"
Steady Rest...........................................1.5" To 6"
Driving Plate.........................................11-3/4"
Center Sleeve.........................................MT#7
Live Center...........................................MT #5
Dead Center (Cemented Carbide Tip) ...................MT #5
Change Gear...........................................60 T
Mirco Carriage Stop...................................Yes
Coolant Pan Only......................................Yes
Thread Dial...........................................Yes
Coolant Pan Only......................................Yes
Hardened And Ground Ways Yes

Optional Accessories Will Be Added To Base Price:

Newall D.R.O. 2 Axis..................................$4,150.00 Installed
Taper Attachment......................................$5,750.00 Installed
Chuck Options:
BTC 16"4-Jaw..........................................$2,450.00
Gator 16" Semi-Steel Chucks, Direct Mount D1-8,
4-Jaw Independent, With 2 Piece Jaws..................$3,615.00
Gator 15" 3-Jaw Scroll Type,
With 2 Piece Jaws Direct Mount D1-8...................$3,450.00
Aloris Type Tool Post And 5 Holders...................$1,450.00
Steady Rest (1.5" To 6")..............................$1,250.00
Roller Jaw Set For Steady Rest........................$525.00
Steady rest Over size (6"-10")........................$2,550.00
Follow Rest...........................................$800.00

Two Years Parts Warranty

Delivery 90 to 120 Days after receipt purchase order and 20% down payment.
