W.F. Wells Model B-24-4 25"X25" Horizontal Saw

Maximum Capacity Round @ 90 Degrees 25"
Rectangular Maximum Cap. Height @ 90 Degrees 25"
Rectangular Maximum Cap. Flat @ 90 Degrees 40"
Maximum Capacity Round @ 45 Degrees 24"
Rectangular Maximum Cap. Height @ 45 Degrees 25"
Rectangular Maximum Cap. Flat @ 45 Degrees 24"
Weight Capacity 15,000 Lbs.
Blade Speed 60 To 500 SFPM
Blade Size 2-5/8" X .063" X 26'6"
Blade Guides Spring Tensioned Carbide Blocks W/ Roller Back
Blade Tension Hydraulic
Band Wheel Size 26"
Vise Hydraulic
Blade Drive 15 Hp., AC Vector Drive
Sawing Force 0-1,000 Lbs.
Coolant Capacity 15 Gallons
Hydraulic Capacity 20 Gallons
Hydraulic Drive 5 Hp.
Work Height 28"
Out-Feed Table 24" X 40"
Vise Jaw Height 17"
Machine Dimensions Length X Width X Height 170" X 52" X 100"
Shipping Weight 8,200 Lbs.
LED Positive Feed Readout Yes
Hydraulic Chip Conveyor, Auger Type Yes
Blade Break / Stall Switch Yes
Hydraulic Positioned Guide Arm Yes
Hydraulic Powered Blade Brush Yes
Blade Tension Indicator Yes
Electronic Door Interlocks Yes
LED Blade Speed Indicator Yes

Prices and Specifications Subject To Change Without Notice:
Optional:
208-60-3 Order Number 0010710
230-60-3 Order Number 0010711
460-60-3 Order Number 0010712
575-60-3 Order Number 0010713
Desription:..................................Order Number......Price
Laser Shadow Line............................00565325..........$2,250.00
Out Board Vise...............................005623............$8,225.00
Discharge Work Table 40" Width X 56" Length..0056225...........$4,750.00
Hydraulic Chip Conveyor, Auger Type..........0056230...........$4,650.00
Out Board Vise With Hydraulic Hold Down......0056231...........$13,985.00
Hydraulic Hold Down, Saw Vise................0056064...........$3,925.00
Non-Powered Conveyor 40" X 5'................0050188...........$3,460.00
Non-Powered Conveyor 40" X 5'................0050182...........$6,375.00
Hydraulic Powered Conveyor 40" X 10'...........................$14,500.00
High Speed Drive & Guides (1-1/4" Blade) 500 To 3,000 SFPM.....$6,450.00

Prices and Specifications Subject To Change Without Notice:
