24"X168" Landis Plain Clyinderical O.D. Grinder

Swing Over Table..............................................24"
Distance Between Centers......................................168"
Diameter Of Grinding Wheel....................................30"
Width Of Grinding Wheel.......................................4"
Diameter Of Grinding Wheel Hole...............................24"
Hydraulic Table Travel........................................2" To 240" I.P.M.
Weight Capacity Between Centers...............................15,000 Lbs.
Hydraulic Motor...............................................2 Hp.
Main Motor Work Head Variable.................................15 Hp.
Main Motor Wheel Head.........................................20 Hp.
Floor Space Front To Back.....................................96"
Floor Space Left To Right.....................................340"
Machine Height................................................84"
Machine Weight................................................32,500 Lbs.
Taper On Table................................................1/4" Per Foot
Work Rest.....................................................4
Tarry Left & Terry............................................Yes
Tail Stock Manual Crank.......................................Yes
Dresser On Tail Stock.........................................Yes
Coolant Tank & Motor..........................................Yes
Swiveling Table.............................................. Yes

Note:
Machine is being cleaned and painted at the present time.
New oil and belts will be installed.
